Roll to Roll Flexography Printer
Home > Products > Flexo Printing Machine > Roll to Roll Flexography Printer

Roll to Roll Flexography Printer

    Payment Type: L/C, T/T, Western Union, Money Gram
    Min. Order: 1
    Productivity: 15 Sets Per Month
    Place of Origin:  Wenzhou, Zhejiang
    Supply Ability: 15 Sets Per Month
  • Mr. Wayne Wang

Basic Info

Model No.:  FM-B920

Product Description

Model NO.: FM-B920 Printing Color: 6 Colors Dryer: IR Embossing Structure: Rotary Letterpress Application: Flexible Packaging Printing Printing Speed: 150m/mim Trademark: Medium Web Flexo Printing Machine Specification: CE SGS HS Code: 8443160090 Printing Page: Double Faced Anilox Roller: Ceramic Anilox Roller Type: Pin-on Structure: Unit Type Automatic Grade: Automatic Machine: Medium Web Flexo Printing Machine Transport Package: Wooden Case Origin: Wenzhou, Zhejiang FM-B920-1850
roll to roll flexography printer
 Roll to Roll Flexography Printer
Roll to Roll Flexography PrinterRoll to Roll Flexography PrinterRoll to Roll Flexography PrinterRoll to Roll Flexography PrinterTechnical Parameters
Specification 35.5(900) 39.5(1000) 47.5(1200)
Max.Web Width 920mm 1020mm 1220mm
Max.Printing Width 900mm 1000mm 1200mm
Max Die-Cutting Width 900mm 1000mm 1200mm
Printing Repeat 286--1200mm 286--1200mm 286--1200mm
Die-cutting Repeat 286--1200mm 286--1200mm 286--1200mm
Max.Unwinder Diameter 1524mm/1200mm 1524mm/1200mm 1524mm/1200mm
Max.Rewinder Diameter 1524mm/1200mm 1524mm/1200mm 1524mm/1200mm
Gearing 1/8cp 1/8cp 1/8cp
Max Printing Speed 150m/min 150m/min 150m/min
Diameter of web roller 100mm 100mm 100mm
Base motor power 15kw-22kw 15kw-22kw 15kw-22kw
Drying mode Warm Drying/IR Drying/ UV Drying
Oil used Aqueous ink/ UV Ink
Power Requirement 380V 3PH 50Hz
Substrate 17g copy paper, cotton paper, 80-450g chrome paper, aluminum-foil paper, BOPP,PET,paper board, kraft paper

Contact us if you need more details on 6 Colors Flexo Printer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Wide Range Flexographic Printer、Paper Printing Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
